Faster command processing:
Quad-core processor for nanosecond speed.
Nearly 3X improvement in overall performance over the previous generation with greater capacity.
Integrated development environment (IDE) for Codesys supports multiple programming languages (LD, FBD, ST, SFC and CFC) in conformity to IEC 61131-3.
Strong bus network:
EtherCAT, EtherNet/IP, OPC UA, Modbus TCP, RS485, CAN bus and other global standard industrial networks.
Two channels of EtherNet built-in switches.
Bus + Pulse for more flexibility and versatility:
EtherCAT includes both real and virtual axes and supports a maximum of 128 axes (32 axes recommended) and 16-axis electronic cam with synchronization cycle of 2ms.
